dehydrator vegetable professional food dehydrator IKE Brand
1. Unmatched expertise of IKE enables us to serve our clients with utmost accuracy than our industry competitors. IKE Industrial is a professional food dehydrator manufacturer
2. The adoption of professional food dehydrator method can cause room dehydrator and satisfy production requirements. We have several production lines to guarantee quality and on-time delivery
3. Our main products cover commercial and residential heat pump water heaters, heat pump dryers, and floor heaters, as well as air conditioners. Because of the features of hot air dryer machine, dehydrator machine,industrial food dehydrator machine becomes most people's choice.
4. Our new launched industrial dehydrator are made to be of industrial dehydrator machine which is harmless to people.Advanced air-source heat pump water heaters, dryers and other environmental protection and energy-saving products are available
WRH-1200A middle temperature industrial large food dehydrator machine is suitable for drying a very large variety of food.
Such as: cloud ear fungus drying, noodle drying, rare chinese herbal drying, pepper drying, small fish drying, flower drying, and so on.
| Specifications for WRH-1200A middle temperature industrial large food dehydrator machine | ||
Main machine WRH-1200A | Material | Stainless Steel |
Capacity | 800~1500Kg | |
Power Supply | 380V-3N / 50Hz / 60Hz | |
Power Input | 13kw | |
Running Current | 20A | |
Fast heating-up | 9kw | |
Maximum Power | 23kw | |
Dehydration Amount | 40Kg/h (@50,80%) | |
Working Temperature | 50-65℃ | |
Noise Level | ≤72dB(A) | |
Wind Volume | 4000m³/h*2 | |
Machine Dimension(L*W*H) | 1800*800*1620mm | |
Net Weight | 350Kg | |
Gross Weight | 370Kg | |
| Drying house | Material | Polyurethane |
| Thinkness | 100m | |
| Size | 5000*2650*2700mm | |
Payment terms | 1, We can offer different pricing of FOB, CIF and C&F. 2, For established customers, we will offer more favorable payment terms. | |
Shipping | 1, We offer FOB Guangzhou and FOB Shenzhen to our customers. | |
WRH-1200A - Front view
There are power line, electrical controller box and exhaust air outlet on the front.
WRH-1200A back view
There are hot and dry air outlets on the back.
Based on the drying characteristics of the material to be dried, customers can build their own drying house. After completion of the drying house, one simply pushes WRH-1200A large food dehydrator into the house and connects it to the power supply. This is very flexible and convenient.
Even if the amount of moisture in the material may not be very high, the inner space of the drying house cannot be too large. An overly sized drying house will affect the efficiency of the food dehydrators.
Using one WRH-1200A food dehydrator
This is the old version of WRH-1200A, new ones all made of mirror finished stainless steel
WRH-1200A food dehydrator drying house with Plastic trays
We usually supply stainless steel trays, and plastic trays are available if required by the customer.
Construction Guild for WRH-1200A industrial large food dehydrator machine drying house
1. Material : 100mm Polyurethane heat-preserved board
2. Size of Drying house (L*W*H) 5000mm×2650mm×2500mm
3. Door Size(W*H): 1100*1900mm
4. There are 6 pcs sandwich foam board used for windshield. size: 1250*950*50mm
5. Can use 3Fans, Model No: GKF/L 4S-2-0.55KW-4 as return airflow . wind speed: 2900rph, as shown on the picture.
6. Installing a foam panel at the fan requires a modular stainless steel support
7. we recommend to open the hole for drying house after installing the machine
Construction Guild For Racks
1. Material : Stainless Steel 201
2. Size of the rack (L*W*H) :1200*850*1750mm
3. There is 25 layer ,distance in between the layer is 60mm, can put 50pcs trays per rack
Detail for Trays
1. Material : stainless Steel 304
2. Aperture：5*5mm
3. Size : 780*540*30mm
Dehydrate long beans by WRH-1200A industrial large food dehydrator machine. It normally can dehydrate 1000kg fresh long beans per batch.
Company Features
1. The dehydrator machine Which Meet People's Requirements In Pursuit Of Good Taste Life. Choose From IKE Food Dehydrator Website, You Will Never Be Disappointed.
2. Guangdong IKE Industrial Co.,Ltd. owns manufacturing facilities.
3. Guangdong IKE Industrial Co.,Ltd. make every effort to have professional food dehydrator in this industrial dehydrator. Get price!
