Hot grade professional food dehydrator industrial IKE Brand
1. The production of dehydrator machine always take professional food dehydrator into account. IKE Industrial is located in the New and High Technology Industrial Park of the City of Meizhou, Guangdong Province
2. IKE promises machine warranty for one year, long-term after-sale spare parts service. IKE has excellent customer service representatives available to help you out by phone.
3. The offered industrial dehydrator is used for room dehydrator in various industries. IKE makes foresighted strategic on equipment automation, management system and so on
WRH-1200A middle temperature industrial large food dehydrator machine is suitable for drying a very large variety of food.
Such as: cloud ear fungus drying, noodle drying, rare chinese herbal drying, pepper drying, small fish drying, flower drying, and so on.
Contact us for free product testing!
SPECIFICATIONS FOR WRH-1200A Middle Temperature Industrial Large Food Dehydrator Machine | ||
Main machine WRH-1200A performance parameters | Materials | Stainless Steel |
Capacity | 800-1500kg/batch | |
Power Supply | 380~3Nv/50Hz/60Hz | |
Power Input | 13.0KW | |
Running Current | 20.0A | |
Fast heating-up | 9.0KW | |
Maximum Power | 23Kw | |
Dehydration Amount | 40.0Kg/h ( @ 50℃，80%） | |
Working Temperature | 50~65℃ | |
Noise Level | ≤72dB(A) | |
Wind Volume | 4000m³/h*2 | |
Machine Dimension(L*W*H) | 1800*800*1620mm | |
Net Weight | 350Kg | |
Gross Weight | 370Kg | |
| Drying house | Material | Polyurethane |
| Thinkness | 100mm | |
| Size | 5000*2650*2700mm | |
| MOQ | 1 unit | |
| Lead time | 10~30 working days | |
Payment terms | 1, We can offer different pricing of FOB, CIF and C&F. | |
Shipping | 1, We offer FOB Guangzhou and FOB Shenzhen to our customers. | |
| Warranty | two-years warranty after WRH-1200A ship | |
The WRH-1200A is an embedded food dehydrator that is the main machine of the drying system. After constructing an insulated drying room, push the WRH-1200A into the drying room and simply connect the power cord to work normally.
You can use your own drying house or buy our IKE drying house.
WRH-1200A - Front view
There are hot and dry air outlets on the back.
WRH-1200A back view
There are power line, electrical controller box and exhaust air outlet on the front.
Based on the drying characteristics of the material to be dried, you can build your own drying house. After completion of the drying house, one simply pushes WRH-1200A industrial large food dehydrator machine into the house and connects it to the power supply. This is very flexible and convenient.
Even if the amount of moisture in the material may not be very high, the inner space of the drying house cannot be too large. An overly sized drying house will affect the efficiency of the WRH-1200A food dehydrator machine.
Using one WRH-1200A food dehydrator
This is the old version of WRH-1200A, new ones all made of mirror finished stainless steel
WRH-1200A food dehydrator drying house with Plastic trays
We usually supply stainless steel trays, and plastic trays are available if required by the customer.
Construction Guild for WRH-1200A industrial large food dehydrator machine drying house
1. Material : 100mm Polyurethane heat-preserved board
2. Size of Drying house (L*W*H) 5000mm×2650mm×2500mm
3. Door Size(W*H): 1100*1900mm
4. There are 6 pcs sandwich foam board used for windshield. size: 1250*950*50mm
5. Can use 3Fans, Model No: GKF/L 4S-2-0.55KW-4 as return airflow . wind speed: 2900rph, as shown on the picture.
6. Installing a foam panel at the fan requires a modular stainless steel support
7. we recommend to open the hole for drying house after installing the machine
Construction Guild For Racks
1. Material : Stainless Steel 201
2. Size of the rack (L*W*H) :1200*850*1750mm
3. There is 25 layer ,distance in between the layer is 60mm, can put 50pcs trays per rack
Detail for Trays
1. Material : stainless Steel 304
2. Aperture：5*5mm
3. Size : 780*540*30mm
Dehydrate long beans by WRH-1200A industrial large food dehydrator machine. It normally can dehydrate 1000kg fresh long beans per batch.
Company Features
1. Guangdong IKE Industrial Co.,Ltd. can deliver dehydrator machine on time and seldom on shortage because we have powerful team to support. - IKE has been more competitive for its high-quality industrial dehydrator.
2. Products offered by IKE have won praise from customers worldwide due to their quality.
3. Strict quality control system enables Guangdong IKE Industrial Co.,Ltd. to implement comprehensive monitoring during the whole process. - As an essential focus, professional food dehydrator plays an important role in the development of IKE. Call!
