1. The design of IKE fruit and vegetable dryer machine is humanized and reasonable. To make it accommodate to different types of foods, the R&D team creates this product with a thermostat which allows adjusting the dehydrating temperature.
2. The product is fire-retardant. Some chemical treatment such as singeing is applied to burn off the surface fibers from the fabric to guarantee its low flammability.
3. Whether the motivations are economic, environmental, or personal, the benefits of this product will have something to offer for everyone.
WRH-500A commercial middle temperature electric digital food dryer is suitable for drying a very large variety of food. Such as pasta drying, herbal Chinese herbal medicine drying, fruit drying and processing, pet food drying, and so on. Contact us for free drying testing!
SPECIFICATIONS FOR WRH-500A Commercial Middle Temperature Electric Digital Food Dryer | ||
Main machine WRH-500A performance parameters | Materials | Stainless Steel |
Capacity | 400kg~600kg per batch | |
Power Supply | 380V~3N/50Hz/60Hz | |
Power Input | 5.0KW | |
Running Current | 15.0A | |
Fast heating-up | 4.5KW | |
Maximum Power | 11Kw | |
Dehydration Amount | 16.0Kg/h ( @ 50℃，80%） | |
Working Temperature | 50~65℃ | |
Noise Level | ≤70dB(A) | |
Wind Volume | 4000m³/h | |
Machine Dimension(L*W*H) | 1800*680*1320mm | |
Net Weight | 170Kg | |
Gross Weight | 190Kg | |
| Drying room | Material | Polyurethane |
| Thinkness | 100mm | |
| Size | 4000*2100*2400mm | |
| MOQ | 1 unit | |
| Lead time | 10~30 working days | |
Payment terms | 1, We can offer different pricing of FOB, CIF and C&F. | |
Shipping | 1, We offer FOB Guangzhou and FOB Shenzhen to our customers. | |
| Warranty | two-years warranty after WRH-500A ship | |
The WRH-500A commercial middle temperature electric digital food dryer is an embedded dryer that is the main machine of the drying system. After constructing an insulated drying room, push the WRH-500A into the drying room and simply connect the power cord to work normally. You can use your own drying house or buy our IKE drying house with the WRH-500A food dryer.
WRH-500A - Front view
There are hot and dry air outlets on the back of WRH-500A.
WRH-500A back view
There are power line, electrical controller box and exhaust air outlet on the back of WRH-500A.
Based on the drying characteristics of the material to be dried, you can build your own drying house. After completion of the drying house, one simply pushes WRH-500A commercial electric digital food dryer into the house and connects it to the power supply. This is very flexible and convenient. Even if the amount of moisture in the material may not be very high, the inner space of the drying house cannot be too large (Suggest to use the following dimensions). An overly sized drying house will affect the efficiency of the WRH-500A commercial electric digital food dryer.
WRH-500A food dryer drying house with stainless steel trolley
We also sell stainless steel trolley, stainless steel trays, and plastic trays. Customers can choose their own.
WRH-500A food dryer drying house with perforeated wind distribution board
This is the old version of WRH-500A, new ones all made of mirror finished stainless steel. When the volume to be dried is relatively large or fluffy and does not easily stick, stack them directly onto a tray to dry.
top view
Construction Guild for WRH-500A food dryer drying house
1. Material: 100mm polyurethane heat-preserved board
2. Size of WRH-500A food dryer drying house (L*W*H): 5000mm×2100mm×2400mm
3. Door Size (W*H): 1100*1900mm you must put the main machine WRH-500A into the drying house first and then install the sideboard , or you can choose two doors so that the width of the WRH-500A food dryer drying house can totally open.
4. There are 4 pcs sandwich foam board used for the windshield. size: 1250*950*50mm
5. Can use 2Fans as return airflow.
6. Installing a foam panel at the fan requires a modular stainless steel support.
7. We recommend opening the hole for drying house after installing the WRH-500A food dryer.
Construction Guild For Racks
1. Material: Stainless Steel 201
2. Size of the rack (L*W*H): 1200*850*1750mm
3. There is 25 layers, distance in between the layer is 60mm, can put 50pcs trays per rack.
Detail for Trays
1. Material: stainless Steel 304
2. Aperture: 5*5mm
3. Size: 780*540*30mm
Dehydrate siraitia grosvenorii by WRH-500A commercial middle temperature electric digital food dryer. It normally can dehydrate 500kg fresh siraitia grosvenorii per batch.
View Video → Siraitia Grosvenorii Drying
camellia seed dehydrating by IKE WRH-500A commercial food dryer.
View Video → Camellia Seed Drying
1. Middle and low temperature dehumidification drying
The IKE WRH-500A food dryer drying fruits and vegetables in 50℃~65℃, articles does no damage, no moldy and maintain nutrition.
2. Use heat pump technology
The IKE WRH-500A food dryer with high efficiency through the use of a heat pump system for removing air humidity.
3. Working in wholly sealed drying room, hygiene and energy conservation
Drying in a closed sealed room, no foreign material pollution. Efficiency is irrelevant to external environment, that can maintain high energy efficiency at all seasons. No hot air and water vapor loss maximize energy recovery.
4. Running Stable, operating easily
Graphical touch control system, automatic intelligent control and demands no human duty after setting.
Company Features
1. Serving as a Chinese primary exporter for electric food dehydrator , Guangdong IKE Industrial Co.,Ltd. has strong capability in R&D.
2. Guangdong IKE Industrial Co.,Ltd. has a strong technology force to produce best affordable dehydrator .
3. Guangdong IKE Industrial Co.,Ltd. seeks long-term developments with our customers to achieve win-win situation. Call! A significant progress has been made in IKE thanks to the implementation of fruit and vegetable dryer machine plan. Call! In order to satisfy users, we provide both high quality food dehydrator amazon and first-rate service. Call! The good quality of industrial dryer machine represents the life pursuit of IKE. Call!
