industrial equipment for drying fruits and vegetables dehydrator for drying IKE
- IKE runs a complete and standardized customer service system to meet the various needs of customers. The one-stop service range covers from details information giving and consulting to return and exchange of products. This helps improve customer's satisfaction and support for the company.
1. The basic materials used in IKE equipment for drying fruits and vegetables are canvas, rubber or high-grade plastic. The choice depends on the use, for example, indoor or outdoor. Climate too plays a significant role like places with high humidity and moisture.
2. Strict internal quality control system to ensure that products meet international standards.
3. The quality of the products can stand the test of time.
4. relies on strong technical strength and 'integrity' business philosophy, to provide customers with quality products and excellent service.
WRH-300G commercial food dehydrating equipment for beef jerky and fruit is suitable for drying a very large variety of food. Such as fruit drying, egg drying, meat drying, fish drying, rice drying, and so on. Contact us for free drying testing!
SPECIFICATIONS FOR WRH-300G Commercial Food Dehydrating Equipment For Beef Jerky And Fruit | ||
Main machine WRH-300G performance parameters | Materials | Stainless Steel |
Capacity | 200kg~350kg per batch | |
Power Supply | 220V/50Hz/60Hz | |
Power Input | 3.0KW | |
Running Current | 15.0A | |
Fast heating-up | 3.0KW | |
Maximum Power | 6.5Kw | |
Dehydration Amount | 10.0Kg/h ( @ 50℃，80%） | |
Working Temperature | 50~80℃ | |
Noise Level | ≤65dB(A) | |
Wind Volume | 2300m³/h | |
Machine Dimension(L*W*H) | 1150*400*840mm | |
Net Weight | 80Kg | |
Gross Weight | 95Kg | |
Drying room | Material | Polyurethane |
Thinkness | 100mm | |
Size | 3600*1200*2000mm | |
MOQ | 1 unit | |
Lead time | 10~30 working days | |
Payment terms | 1, We can offer different pricing of FOB, CIF and C&F. | |
Shipping | 1, We offer FOB Guangzhou and FOB Shenzhen to our customers. | |
Warranty | two-years warranty after WRH-300G ship | |
The WRH-300G commercial food dehydrating equipment is an embedded dehydrator that is the main machine of the drying system. After constructing an insulated drying room, push the WRH-300G food dehydrating equipment machine into the drying room and simply connect the power cord to work normally. You can use your own drying room or buy our IKE drying room with the WRH-300G food dehydrating equipment machine.
WRH-300G - Front view
There is hot and dry air outlet on the back of WRH-300G. It looks the same as WRH-300A
WRH-300G - back view
There are power line, electrical controller box and exhaust air outlet on the back of WRH-300G. It looks the same as WRH-300A
Based on the drying characteristics of the material to be dried, you can build your own drying room. After completion of the drying room, one simply pushes the food dehydrating equipment machine into the room and connects it to the power supply. This is very flexible and convenient. Even if the amount of moisture in the material may not be very high, the inner space of the drying room cannot be too large (Suggest to use the following dimensions). An overly sized drying room will affect the efficiency of the commercial food dehydrating equipment.
View Video → WRH-300G commercial food dehydrating room
WRH-300G commercial beef jerky dehydrating equipment
Shown here is the meat dehydrating.
WRH-300G commercial fruit dehydrating equipment drying with stainless steel shelves
Shown here is the momordica grosvenori dehydrating
Side View
Construction Guild for WRH-300G commercial food dehydrating equipment for beef jerky and fruit drying house
1. Material: 100mm Polyurethane heat-preserved board
2. Size of WRH-300G commercial food dehydrating equipment drying room: (L*W*H) 3000mm×1450mm×2000mm
3. Door Size (W*H): 1100*1900mm
4. There are 3 pcs sandwich foam board used for windshield. size: 1250*950*50mm
5. Can use Fan Model No :GKF/L 4S-2-0.55KW-4 as return airflow . wind speed : 2900rph, as shown on the picture.
6. Installing a foam panel at the fan requires a modular stainless steel support.
7. We recommend to open the hole for drying room after installing the WRH-300G commercial food dehydrating equipment.
Construction Guild For Racks
1. Material: Stainless Steel 201
2. Size of the rack (L*W*H):1200*850*1750mm
3. There is 25 layer, distance in between the layer is 60mm, can put 50pcs trays per rack
Detail for Trays
1. Material: stainless Steel 304
2. Aperture: 5*5mm
3. Size: 780*540*30mm
Tea dehydrating by IKE WRH-300G commercial food dehydrating equipment.
View Video → Tea Drying
1. Middle and low temperature dehumidification drying
The IKE WRH-300G commercial food dehydrating equipment for beef jerky and fruit drying in 50℃~80℃, articles does no damage, no moldy and maintain nutrition.
2. Use heat pump technology
The IKE WRH-300G commercial food dehydrating equipment with high efficiency through the use of a heat pump system for removing air humidity.
3. Working in wholly sealed drying room, hygiene and energy conservation
Drying in a closed sealed room, no foreign material pollution. Efficiency is irrelevant to external environment, that can maintain high energy efficiency at all seasons. No hot air and water vapor loss maximize energy recovery.
4. Running Stable, operating easily
Graphical touch control system, automatic intelligent control and demands no human duty after setting.
Company Features
1. IKE is a dominant supplier integrating design, research and development, production, sales and service of commercial food dehydrator .
2. IKE has made a great success in improving the performance of electric food dehydrator .
3. firmly believes that high quality and professional services will ultimately pay off. Contact us! The value of would be to supply each supplier with high quality fruit dryer. Contact us! IKE looks forward to working with you by providing our fantastic dehydrator machine . Contact us!
